Aqua Max Digital Pool Timer – 7 Day Programmable

The Aqua Max digital pool timer switches your pool pump or geyser on and off automatically, so it only runs when you need it. Because you can set a different schedule for each day of the week, it is easy to cut running hours and save electricity. As a result, your pool stays clean and your geyser stays hot without wasting power.

Why Choose a Digital Pool Timer?

• Up to 16 on/off programs: First of all, you can set up to 16 on and 16 off times across the week.
• Accurate to the minute: In addition, the minimum setting is 1 minute, so you control exactly how long the pump runs.
• Battery backup: A built-in lithium battery keeps the time and your programs during power cuts and load shedding.
• Manual override: Moreover, a single button switches the load on or off without changing your programs.
• Clear LCD display: The screen shows the time, day and current status at a glance.
• DIN rail mounting: Finally, it clips onto a standard 35mm DIN rail inside your distribution board.

Using a Digital Pool Timer for Your Pump and Geyser

For a pool pump, most pools need the water turned over at least once a day. In summer, that usually means 6–8 hours of filtration. In winter, however, you can often cut back to 4–6 hours. For a geyser, set the timer to heat water before your morning and evening peaks instead of all day. In other words, you keep hot water ready while the element works less.

Installation

A registered electrician should install and wire the timer. The relay is rated at 30A for resistive loads such as a geyser element, and 16A for inductive loads such as a pump motor. For larger pumps, or when your electrician prefers, the timer can switch a contactor instead of the load directly. You can find boards and spares in our pool distribution boards range.

Specifications

• Brand: Aqua Max
• Product type: 7 day digital pool timer
• Supply voltage: 220–240V AC
• Resistive load: 30A
• Inductive load: 16A
• Programs: Up to 16 on / 16 off per week
• Minimum interval: 1 minute
• Backup: Built-in lithium battery
• Operating temperature: -10°C to +40°C
• Mounting: 35mm DIN rail

What’s in the Box

1 x Aqua Max 7 day digital pool timer. In short, order online from Pool DC for delivery across South Africa, or browse our pool pumps.
